570500 Pilz Coded Non-Contact Safety Switches PSENSLOCK Series


Overview Pilz Coded Non-Contact Safety Switches PSENSLOCK Series Item# 570500 - PSEN SL-0.5P 1.1 CODED M12 8-Pin Connector PSENSLOCK Series Information Non-Contact Coded Operation Holding Force to 1000 Newtons High Degree of Manipulation Protection Diagnostic Interface with 4 LEDs IP67 Protection The PSENslock non?contact safety gate system from Pilz offers a safe alternative to existing mechanical technology. PSENslock combines secure safety gate monitoring and a non?contact magnetic interlock within one unit. With this combination of safe position monitoring and process guard locking PSENslock can be used universally for right or left?hinged swing gates and sliding gates and is particularly suitable for use on movable guards. With an electromagnetic holding force of 500 or 1000 Newtons the PSENslock prevents swing gates and sliding gates from being opened unintentionally. The actuator is manipulation?proof providing added safety. With its compact design the process guard?locking device is extremely suitable for mounting on to standard 45 mm profiles. PSENslock is designed for applications up to SIL 3 in accordance with IEC 62061 Category 4 in accordance with EN 954?1 and protection type IP67. In terms of a complete solution PSENslock can be connected to all Pilz evaluation devices. Mechanically Non?Wearing ? Long Service Life Ideal for Rugged Industrial Applications Insensitive to Dust and Water Specifications Item Number: 570500 UPC: 4046548050837 Brand: Pilz Item Category:Safety Switches Subcategory: Coded Non-Contact Series: PSENSLOCK Guard Locking: Yes Outputs: 2 Semiconductor Aux Outputs: 1 Semiconductor Switch On Distance: 1 MilliMeters Switch Off Distance: 8 MilliMeters Holding Force: 500 Newtons Operating Voltage: 24 VDC Connection Type: 8 Pin M12 Connector Protection Rating: IP67 Approvals: UL;cUL;TUV Picture No.: PILZ_SAFTSWIT_PSENSLOCK-0.5P H x W x D: 4.8 in x 1.77 in x 1.73 in
